Feature Summary
- New model Classier and sturdier rectangular profile, available in Black or Silver, 50% more power leds and
high tech driverless technology!
- Amazing Colour Pop, colour saturation and Awesome shimmer!
- Fully dimmable, control via manual dimmer or app
- Safe low 24VDC for your safety
- Anti Glare Rhombus optic lenses for crisp, clear and vibrant colours
- Ultrabright 3 Watt Power Leds
- Small 2cm x 3cm footprint and light weight 150g per 30cm
You Choose the Length and Spectrum
NOTE: This is a tube only, no power supply. To be used as an add on or replacement.
Fixed Spectrum Spare/Replacement Tubes (aka XB5) are for building custom systems or for use aas a spacre or replacement.
As a guide, the Flora Sun Blend is the most popular for fresh water tanks because it naturally highlights blues and reds in fish and also has a perfect spectrum for growing
plants and the 120000K Coral Sun tube is the most popular for marine tanks.
High Tech Anti Glare Rhombus lenses
These power led tubes feature high tech 2-in-1 Anti Glare Rhombus Optic lens and reflectors for maximum output and awesome shimmer! Available in 120°, 90°, 60°, 45° and 30° beam angles to target specific depths and to achieve specific PAR. Lenses can be easily DIY swapped if your needs change.
Available in Black or Silver
These Fixed Colour lights are available in smooth anodised Silver or Black colour.
Hood Mounting
Hood mounting requires a little diy because all hoods are different, each tube comes with a pair of universal mounting clips to help make this an easy job.
NOTE: You should have adequate airflow under the hood to prevent overheating and have glass lids to prevent excess humidity.
Doing this will LED lights will have a will have
Glasstop Mounting
And finally, the tubes are so light and compact they can be laid directly on glass lids.
Most of the heat on these lights is projected upwards and very little heat is projected down so the glass won't get too hot.
Whats In The Box
- 1 x Fixed Spectrum Spare/Replacement Tube 30,60,90,120,150 or 180cm lenth
- Universal mounting clips
Beam Angle Choice For Fresh Water
| Total Height |
Tank Style |
| Live Plants & CO2 |
Live Plants no CO2 |
No live Plants |
| 15cm |
120° |
120° |
120° |
| 30cm |
120° |
120° |
120° |
| 45cm |
120° |
120° |
120° |
| 60cm |
90° |
90° |
120° |
| 75cm |
60° |
90° |
90° |
| 90cm |
45° |
60° |
90° |
| 100cm |
30° |
45° |
60° |
The beam angle affects how wide or narrow the light beam will be. A lower degree beam angle like 30 will have a narrower beam than 45.
Narrower beams produce higher intensity and PAR directly below the light but that intensity tapers off as you move out from the center.
Wider beams have a lower intensity and PAR directly below but the intensity does not taper off as quickly.
Choosing an appropriate beam angle for your tank dimensions and lighting needs is not an exact science but use this table as a general guideline.
Optic lenses are DIY swappable so if you change your mind later you can buy a different beam angle and swap them over.
Beam Angle Choice For Salt Water
| Total Height |
Tank Style |
| Mixed corals inc SPS |
LPS & Softies |
No Live Corals |
| 15cm |
120° |
120° |
120° |
| 30cm |
120° |
120° |
120° |
| 45cm |
90° |
120° |
120° |
| 60cm |
60° |
90° |
120° |
| 75cm |
45° |
60° |
90° |
| 90cm |
30° |
45° |
60° |
| 100cm |
30° |
45° |
60° |
The beam angle affects how wide or narrow the light beam will be. A lower degree beam angle like 30 will have a narrower beam than 45.
Narrower beams produce higher intensity and PAR directly below the light but that intensity tapers off as you move out from the center.
Wider beams have a lower intensity and PAR directly below but the intensity does not taper off as quickly.
Choosing an appropriate beam angle for your tank dimensions and lighting needs is not an exact science but use this table as a general guideline.
Optic lenses are DIY swappable so if you change your mind later you can buy a different beam angle and swap them over.
Specs
| Model |
MML-FSXB5-TUBE |
| Name |
Fixed Spectrum Spare/Replacement Tube |
| Cabling |
Each tube ha a 2 metre cable that exits from the end of the tube, plug type is a 5.5/2.1 barrel plug ready to connect directly to a dimmer or 24V power supply. |
| Voltage |
110-240V AC Input, Operating voltage 24V DC |
| Dimming |
Dimmable, less brightness uses less power |
| Power |
9 watts per 30cm of tube |
| LEDS |
Epistar power leds arranged as shown in the pictures |
| Cooling |
Passively cooled, heat is dissipated naturally. |
| IP Rating |
IP64 |
| Beam |
Your choice of 120°, 90°, 60°, 45° and 30° for targeted depths up to 2 metres |
| Shimmer |
Creates a beautiful shimmer in the water like natural sunlight on a clear pond when the surface is rippled |
| Spectrum |
You choose the spectrums you need |
| Warranty |
2 Years |
| Build |
 |
PAR
| Beam Angle |
Height from light to bottom of tank in cm |
| 15 |
30 |
45 |
60 |
75 |
| 120° |
183 |
135 |
100 |
73 |
54 |
| 90° |
198 |
146 |
107 |
78 |
57 |
| 60° |
214 |
158 |
117 |
85 |
62 |
| 45° |
232 |
182 |
134 |
98 |
71 |
| 30° |
278 |
218 |
160 |
117 |
86 |
The PAR shown in the table is for one Flora Sun Tube. Some spectrum tubes have higher PAR than this e.g.6500K Cool White, and some have lower e.g. Deep Red Highlighter.
PAR will be approx 88% higher for more multi tube sets.
- This is a high light system and is fully dimmable so you can run it at lower than full capacity if you don't need that much light.
If you want to add more lights to this set later we'll provide a power supply and cabling capable of running up to 5 x 60cm lights
Look in the product description for mounting hardware details. Each bracket has room for up to three lights or you can buy more brackets from our Accessories page if you want to spread the lights out.
0
See main description for more info
Choose Yes include a Power Supply if you don't already have one
For multi tube sets, 1 dimmer only means it will control all tubes together, 1 dimmer per tube means you can dim each tube separately.
